                                           Printed Circuit Boards





-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

..............................................

Products Scope                                        We manufactures and supplies Printed Circuit

Products exhibition                                               Boards for the electron field and  brings you high

Double sided PCB                                     quality PCBs from 1 layer to 20 layer.

4-layer PCB

Multiplier PCB

..............................................



ISO9001

Our PCB manufacturing is ISO9002 certified and our PCB assembly and electronic hardware manufacturing is ISO9001 certified.  And provide RoHS Product. Many  years experience of PCB, and got IS014000 and UL certificates.

Today, eleclink is emerging as an electronic partner with the management depth, resources and expertise and the flexibility and agility.   This makes it easier for our customers to innovate, compete and continue to drive down the cost of electronic products. Our manufacturing is very flexible, and can meet needs as varied as small volume 2-layer prototypes, up to huge volume 20-layer mass productions.

We  provide you PCB product with high quality you can trust,  Our sales and customer service team is always ready to answer your questions  and meet your needs! We offer 100% quality warrantee, shipping lead time guarantee and  lower price guarantee  in North  Americans market and in Europe market and other regions market.

Performance:

                       ·Blind and Buried via PCB
                       ·Immersion gold plating PCB
                       ·High frequency PCB
                       ·High TG (170C) PCB
                       ·Free halogen PCB
                       ·Impedance control PCB
                       ·Different PCB surface finish:  HAL, Flash
                          gold,  Immersion gold, Goldconnectors;
                       ·Colorful solder mask PCB
                       ·PCB Bwith Bridge Connecting
                       ·RoHS

Low Pricing for Small PCB Order with low cost-high quality manufacturing

                        The following chart are price samples for small orders of
                        a 3.5" x 4.5" board. The price unit is USD, Lead time is
                        2~6 weeks. Standard Lead time is 2 weeks.
                        However for fast PCB, the lead time can be 3 days to 6 weeks
                        depending on customers' needs.
                        Please note:   Discount for Re-Orde . All price including VAT
                        All price  are FOB anywhere for North America and Europe
                        and for global electronic makers

PCB Quote Size:  3.5" x 4.5"  board(1 PCS).
The price unit is USD per 1 PCS.
For 5-50PCS PCB Order.

  2 weeks

2 Layers

4 Layers

6 Layers

8 Layers

10 pcs/each

$5.90

$14.00

$21.07

$28.00

 10 Re-Order

$5.31

$12.60

$18.96

$25.20

25 pcs/each

$3.60

$8.37

$14.00

$18.60

25 Re-Order

$3.24

$7.53

$12.60

$16.74

50 pcs/each

$2.02

$5.65

$8.50

$11.30

50 Re-Order

$1.82

$5.09

$7.65

$10.18

Plus set up and Test charge $59  for 2-layer board
Plus set up and Test charge $130 for 4-layer board
Plus set up and Test charge $190 for 6-layer board
Plus set up and Test charge $253 for 8-layer board




Double sided 3" x 4"  board
The price unit is USD per 1 PCS
For 50-500PCS PCB Order

Unit

2 Weeks

         50 pcs/each

$1.99

50 Re-Order

$1.79

       100 pcs/each

$1.89

100 Re-Order

 $1.70

       500 pcs/each

$1.10

500 Re-Order

 $1.00

Plus set up and Test charge $59 for 2-layer board




4-layer 3" x 4"  board
The price unit is USD per 1 PCS
For 50-500PCS PCB Order

Unit

2 Weeks

50 pcs/each

$4.20

50 Re-Order

 $3.54

100 pcs/each

$3.46

100 Re-Order

 $2.92

500 pcs/each

$2.47

500 Re-Order

$2.09


Plus set up and Test charge $130 for 4-layer board




Low Pricing for Large PCB Order with low cost-high quality manufacturing

The price unit is USD per sq.in.  For 5000PCS PCB Order

Unit

2 Layers

4 Layers

6 Layers

5,000 pcs (50k, sq. in

$0.057

 $0.122

 $0.193

5,000 pcs (100k sq.in)

 $0.053

$0.113

$0.182

5000 pcs (200k sq.in)

 $0.048

 $0.102

$0.170





                                                           The Pricing is valid for Standard production:



                                                          ·Basematerial: FR4, 1.55mm (0.062" thick board)
                                                          ·Minimum hole: 0,3mm(0.012")
                                                          ·Copper thickness : 35µm Cu (1 oz plating layers)
                                                          ·Trackwith/space: 0.25/0.25mm min. (0.0098" min.)
                                                          ·Plating: HAL , Electrolytic gold (hard gold)
                                                          ·V-cut, Milled Outline
                                                          ·Max Board dimensions:  635mmx406mm
                                                          ·Solderstop: 2X
                                                          ·Silkscreen Marking Print: 2X
                                                          ·E-Test
                                                          ·Pd-free







                                                          Lead time:



                                                          Standard Lead time is 2 weeks.  The lead time can be 3 days

                                                          to 6 weeks depending on customers' needs. If your specifications

                                                          are different, please contact to sales@eleclink.com for our

                                                          100% low price guaranteed quote.


                                                          Get a faster quoted price and uiltru-fast PCB bord made:
                                                          If you want to make uiltru-fast PCB rice and uiltru-fast PCB board

                                                          made:  PLS click the online  Faster PCB quote

                                                          The lead time can be 2 days.







                                                          Payment:



                                                          Payments can be made by wire transfer the funds to account appointed
                                                          or mail a check to address appointed . To qualify for an 30 account,

                                                          However, we request that new customer orders should be paid by wire

                                                          transfer the funds  to avoid any delays in processing or shipping.





                                                          Information on Delivery Time


                                                          Standard Delivery time is 12WD if:
                                                                            - more than 500 pcs
                                                                            - other material than FR4
                                                                            - special options like blind or buried vias,
                                                                              technology smaller 100 µm
                                                                            - more than 8 layers
                                                                            - custom-made requirements
                                                           The day of order counts as working day after receipt
                                                           of producible production data, in Gerber format (also
                                                           possible)and drill program , not later than 09:00 o`clock.
                                                           We state explicitly: Day of dispatch does not count as working day.












Our Capabilities

                                PCB (Printed Circuit Board)



 Technology  parameter

  Data

 Min. Line Width/Spaces(mils) 2.0/2.0  (0.004" (0.1 mm))
 Max. Layer Count 20
 layer to layer registration tolerance (mil) 4(0.006(0.15mm))
 Board thicknessDouble-sided:0.02", 0.031", 0.039", 0.047", 0.062", 0.078", 0.094"             Maximum board thickness :0.13"
 Base materialsFR-4, FR-406, FR-408, FR-5, G10, CEM3
 Copper foil0.5 oz, 1 oz, 2 oz, 4 oz, 6 oz
 Min. PTH - Mechanical (mils)6  (0.008" (0.2mm))
 Max. Aspect Ratio 10:1
 Impedance Control(%) 5
 Tolerance of board thickness(mm) +/-0.05( Board thickness less than 1.0mm )
 Tolerance of board thickness(mm) +/-5%( Board thickness more than 1.0mm )
 Silkscreen/Legend colorswhite, black, yellow, pink, red
 Solder MaskGreen, Yellow,  Red, Blue, Purple, Silver, Gold, Black
 Gold finger/Max gold thickness 1.25 mm (50 micro-inches)
 PlatingHAL Lead-tin, Immersion gold , Immersion nickel, Electrolytic gold , Immersion tin, OSP
 Lead free Process High Tg/Haloge Rree (>180℃)
 Flatness 0.1%
 Thin board(mm) Small Volume( 0.05 )
 Thick board(mm) 10.0
 Buried resistor/Capacitance Embedded Resistance



Our Online PCB quoting program will instantly generate a quote upon your submission of a request. Please you click

Online Quoting For PCB.
