PCB Quote
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
The standarded lead time can be 2 weeks for double sided and for 4-layer PCB.
You just need to offer followwing:(For Standard production )
Basematerial: FR4, 1.55mm (0.062" thick board)
Minimum hole: 0,3mm(0.012")
Copper thickness : 35µm Cu (1 oz plating layers)
Trackwith/space: 0.25/0.25mm min. (0.0098" min.)
Plating: HAL , Electrolytic gold (hard gold)
V-cut, Milled Outline
Max Board dimensions: 635mmx406mm
Solderstop: 2X
Silkscreen Marking Print: 2X
E-Test
Pd-free
LOWER PRICE Low Price for Small PCB Orders:
The following chart are price samples for small orders of
a 100mm x160mm board. The price unit is USD, Lead time is
2~6 weeks. Standard Lead time is 2 weeks.
However for fast PCB, the lead time can be 3 days to 6 weeks
depending on customers' needs.
Please note: Discount for Re-Orde . All price including VAT
All price are FOB anywhere for North America and Europe
and for global electronic makers
Double sided up to 20-layer PCB
PCB Quote Size: 100mm x160mm board(1 Eurocard).
The price unit is Euromoney(�) per 1 eurocard.
For 5-50PCS PCB Order.
2 weeks | 2 Layers | 4 Layers | 6 Layers | 8 Layers |
5 pcs/ea | 11.47 | 22.00 | 33.12 | 44.01 |
5pcs Re-Order | 10.32 | 19.80 | 29.81 | 39.61 |
10 pcs/ea | 5.64 | 13.39 | 20.16 | 26.79 |
10 Re-Order | 5.08 | 12.06 | 18.14 | 24.11 |
25 pcs/ea | 3.44 | 8.00 | 13.39 | 17.80 |
25 Re-Order | 3.10 | 7.20 | 12.06 | 16.02 |
50 pcs/ea | 1.93 | 5.41 | 8.13 | 10.81 |
50 Re-Order | 1.74 | 4.87 | 7.32 | 9.74 |
Plus set up and Test charge 47 � for 2-layer board
Plus set up and Test charge 104 � for 4-layer board
Plus set up and Test charge 149 � for 6-layer board
Plus set up and Test charge 199 � for 8-layer board
Double sided 76mm x100mm board
The price unit is Euromoney(�) per 1 eurocard.
For 50-500PCS PCB Order
Unit | 2 Weeks |
50 pcs/ea | 1.90 |
50pcs Re-Order | 1.71 |
100 pcs/ea | 1.81 |
100pcs Re-Order | 1.63 |
500 pcs/ea | 1.05 |
500pcs Re-Order | 0.96 |
Plus set up and Test charge 47 �
4-layer76mm x100mm board
The price unit is Euromoney(�) per 1 eurocard.
For 50-500PCS PCB Order
Unit | 2 Weeks |
50 pcs/ea | 4.02 |
50pcs Re-Order | 3.39 |
100 pcs/ea | 3.31 |
100pcs Re-Order | 2.79 |
500 pcs/ea | 2.36 |
500pcs Re-Order | 1.99 |
Plus set up and Test charge 104 �
The price unit is Euromoney(�) per 1 sq. m
For 5000PCS PCB Order
Unit | 2 Layers | 4 Layers | 6 Layers |
5,000 pcs (50K, sq. m) | 84.52 | 180.91 | 286.20 |
5000pcs Re-Order | --- | --- | --- |
5,000 pcs (110k, sq. m) | 78.59 | 167.57 | 269.89 |
5000pcs Re-Order | --- | --- | --- |
5,000 pcs (250k,sq. m ) | 71.18 | 151.25 | 252.09 |
5000pcs Re-Order | --- | --- | --- |
The Pricing is valid for Standard production:
·Basematerial: FR4, 1.55mm (0.062" thick board)
·Minimum hole: 0,3mm(0.012")
·Copper thickness : 35µm Cu (1 oz plating layers)
·Trackwith/space: 0.25/0.25mm min. (0.0098" min.)
·Plating: HAL , Electrolytic gold (hard gold)
·V-cut, Milled Outline
·Max Board dimensions: 635mmx406mm
·Solderstop: 2X
·Silkscreen Marking Print: 2X
·E-Test
·Pd-free
If no standard spec, please notice specialties in order.
The lead time can be 2 days for double sided and 3days for 4-layer PCB.
Working Days |
8 | 7 | 6 | 5 | 4 | 3 | 2 |
Surcharge | 0 % | 40 % | 60 % | 80 % | 100 % | 125 % | 150 % |
